Description:

Z Master® 6000 Series EFI models feature Horizon Technology, an onboard intelligence platform that improves fuel efficiency and productivity. This feature allows communication between key systems on the machine to enhance performance in a wide range of mowing conditions. This Z Master® 6000 Series mower has a 29 HP Kawasaki® FX EFI 999cc w/Horizon™ Technology Engine with 60" (152.4 cm) TURBO FORCE® deck.

Features:

• Our TURBO FORCE deck features heat-treated steel blades and our patented adjustable discharge chute, nothing cuts as fast or as well
• Deluxe suspension seat features thick cushions, large bolsters and 3-D isolator mounts that absorb bumps and vibrations to reduce operator fatigue, fully adjustable to match operator comfort
• Unitized pump and wheel motor uses proven commercial hydraulic components while eliminating hoses and other potential leak points

Specifications:

• Engine Brand: Kawasaki® FX850V EFI with Horizon™ Technology
• Engine Displacement: 852 cc
• Engine Horsepower: 29.5 hp (22 kW)
• Fuel Type: Gasoline
• Fuel Capacity: 12 gal. / 45.4 L / 48 Qt.
• Start Type: Electric
• Hour Meter: Standard

Drive System:

• Transmission: Unitized Pumps 16cc and Wheel Motors 17.1 cir
• Drive Tires: 24" x 12" – 12" (61 cm x 30.5 cm – 30.5 cm) Pneumatic
• Caster Tires: 13" x 6.5" – 6" (33 cm x 16.5 cm – 15.2 cm) Flat-Free Semi-Pneumatic
• Forward Ground/Transport Speed: Up to 11.5 mph / 18.5 kph

Deck Specifications:

• Deck Size: 60 in / 152 cm
• Deck Material: 7 Gauge Steel
• Deck Design: 80-Grade 7-Gauge TURBO FORCE® Deck with Reinforced Bull-Nose Bumper
• Blades: 0.25 in. (0.6 cm) heat-treated steel
• Blade Tip Speed: 18,500 ft/min (5,638 m/min)
• Discharge Chute: Rubber
• Adjustable Discharge Baffle: Standard, Tools-Free
• Height of Cut: 1.0 - 5.5 in. / 2.5 - 14.0 cm

Chassis and Comfort Features:

• Carrier Frame: 3" x 1.5" x 10 gauge (7.6 cm x 3.8 cm x 10 gauge)
• Seat: Handcrafted Deluxe Suspension Seat with Arm Rests Featuring Bullhorn Accent
• Roll-Over Protection System (ROPS): Folding, Standard
• Spindle Bearings: Greaseless Ball Bearings
• Spindle Housing: 9 in / 22.9 cm Diameter Cast Aluminum
• Front Bumper: Reinforced Bull-Nose
• Steering Controls: 1-5/8" (4.1 cm) Diameter Grips; Adjustable, Dampened

Other Details:

• Hydraulic Fluid: Premium Synthetic
• Box Dimensions: 91.5 in. x 70.5 in. x 52.5 in. / 232.4 cm x 179.1 cm x 133.4 cm
• CARB Compliant: No (Not CARB Compliant)
