Description:

The FSA 135 battery brushcutter is the right choice for the maintenance of green areas in noise-sensitive environments by yard and landscape maintenance professionals or local authorities. With its ergonomic bike handle, you can mow larger lawns comfortably and effectively.

Thanks to the powerful EC motor and the wide range of STIHL® cutting tools that you can use with this brushcutter, the FSA 135 is ideal for green area maintenance and mowing grass and scrub. The brushcutter’s ergonomic control handle enables you to adjust the speed on an infinitely variable basis. To work as efficiently as possible and conserve energy, you can choose between 3 speed settings. Power-saving mode is indicated by an LED. An air filter with a metal grille ensures a long service life by providing optimum engine cooling. This air filter is also easy to clean. The power tool housing of the FSA 135 has a dedicated position for the STIHL® Smart Connector 2 A.

Our overview of STIHL® battery life and charging times shows how long you can work with your STIHL® FSA 135 battery brushcutter and how long the installed battery takes to charge.

All battery power tools within the STIHL® AP System have been designed for professional use and daily application, including in adverse weather conditions. With that in mind, they are certified as splash proof; the effectiveness of this is also verified through demanding internal checks. The splashwater test meets the IPX4 standard, among others.

 Features

1. Easy Adjustment of Power Tool Performance

• Description: Adjust the speed of your power tool effortlessly to match the work situation. This feature minimizes energy consumption at lower speeds, extending battery life.
• Benefit: Allows you to maintain productivity without changing your grip or pausing work, thanks to the practical control handle with integrated speed control.

2. Optimal Engine Cooling

• Description: The air filter, featuring a fine metal mesh, effectively cleans the air, ensuring optimal engine cooling.
• Benefit: The filter is easy to clean and provides a long service life, enhancing overall engine performance and longevity.

Specifications:

Rated Voltage: 36 V

Weight:

• 4.9 kg (10.8 lbs)

Sound Levels:

• Sound Pressure Level: 80 dB(A)
• Sound Power Level: 92 dB(A)

Vibration Levels:

• Left Handle: 2.9 m/s²
• Right Handle: 2.0 m/s²

Dimensions:

• Overall Length: 188 cm
• Cutting Circle Diameter: 420 mm

Standard Cutting Attachment:

• AutoCut C 26-2 mowing head

Recommended Batteries:

• AP 300 S
• AR 2000

Battery Life:

• With AP 100: Up to 25 min
• With AP 100 (2): Up to 14 min
• With AP 200: Up to 50 min
• With AP 200 (2): Up to 28 min
• With AP 300: Up to 70 min
• With AP 300 (2): Up to 36 min
• With AP 300 S: Up to 100 min
• With AP 300 S (2): Up to 45 min
• With AP 500 S: Up to 120 min
• With AP 500 S (2): Up to 54 min
• With AR 1000: Up to 200 min
• With AR 1000 (2): Up to 100 min
• With AR 2000: Up to 300 min
• With AR 2000 (2): Up to 150 min
• With AR 2000 L: Up to 310 min
• With AR 2000 L (2): Up to 160 min
• With AR 3000: Up to 420 min
• With AR 3000 L: Up to 430 min
• With AR 3000 L (2): Up to 220 min

Tool Battery Life: Stage 1 with GSB

IPX Rating: N/A
