Description:

Split big logs in either horizontal or vertical position (great for logs that are too heavy to lift). Switch configurations in seconds without tools. DR 6.6 HP engine, 12-second cycle time. Road-towable at speeds up to 45 mph.

Features:

  • Easy Conversion: Switching from horizontal to vertical mode (or vice versa) takes only a few seconds. Just slip out a pin, rotate the unit, and re-insert pin to lock it into position. Lets you split those really big rounds without lifting the log onto the beam.
  • DR Engine: Easy-starting DR 6.2 HP engine powers the hydraulic pump. Warranted for 2 years in residential use (90 days commercial).
  • Rugged Hydraulics: Hydraulic pump generates 3700 psi in the cylinder (4.1 in. bore). Steel piston compression seals provide consistent power...year after year.
  • Easy Towing: A 2 in. ball hitch comes standard (with safety chains) allowing for road towing at speeds up to 45 mph. Durable, 16 in. DOT-approved tires. Jackstand folds up for transport.

Dimensions

  • Height: 40.6 in.
  • Length: 89.5 in.
  • Shipping Weight: 530 lb.
  • Wedge Height: 7 in.
  • Weight: 530 lb.
  • Width: 51.3 in.
  • Shipping Dimensions: 71 in.L x 27 in.W x 20 in.H
  • Working Height: 30 in.

Engine

  • Air Filter: Dual Element
  • Cooling Methods: Air
  • Displacement: 223cc
  • Engine Type: OHV
  • Horsepower: 6.6 HP
  • Lubrication: Splash
  • Make: DR
  • Number Of Cylinders: 1
  • Oil Capacity: 16.9 oz
  • Oil Type: SAE 30W HD
  • RPM Speeds: 3600
  • Starting Type: Manual

Fuel System

  • Fuel Capacity: 0.8 gal.

General

  • CARB Certified: Yes

Hydraulics

  • Hydraulic Flow: 11 gpm
  • Hydraulic Pressure: 4100 PSI MAX
  • Pump: 2 stage / 11-13 gpm (max)
  • Reservoir: 4 gal.

Wheel Tires

  • Number of Tires: 2
  • Tire Size: 16 in. x 4.8 in. Tube Tires
  • Wheel: Steel Wheel with Taper Roller Bearings

Warranty

  • Engine Warranty: 2 Year Residential, 1 Year Commercial
  • Machine Warranty: 2 Year Residential, 90 Day Commercial

Towing

  • Hitch Type: 2 in. Ball
  • Max Highway Speed: 45 MPH
  • Towable: Yes

Splitting

  • Average Cycle Time: 12 Seconds
  • Max Log Diameter: 30 in.
  • Max Log Length: 24 in.
  • Splitting Force: 28 ton
  • Engine Type: OHV
  • Engine Manufacturer: DR
