One NEW  Briggs & Stratton I/C OHV Horizontal Engine — 205cc, 875 Series, 8.75 Gross Torque, 3/4in. x 2 27/64in. Shaft,

 Model# 122032-0536-B8 = 130g32-0022-f1

bin 130g32-0022-f1

Briggs & Stratton 205cc 875 Series™ Industrial/Commercial Horizontal Engine produces 8.75 ft.-lbs. Gross Torque to get the job done.

Compact overhead valve design runs cooler and cleaner delivering more power, longer engine life and improved fuel economy.

High flow cylinder head produces 20% more power than conventional engines, increased fuel efficiency and significantly reduced emissions.

This engine has fast fuel delivery for One-Pull starts and smooth operation.

Self-lubricating heavy-duty bearing is made of steel-backed Teflon coated bronze to withstand load and reduce wear. Dura-Bore™ cast iron sleeve withstands wear and abuse while providing improved oil control.

 Fuel shutoff valve makes it easy to shut off fuel flow for safe transportation. Mechanical governor controls the throttle to deliver more power for tough chores.

Not for sale in California (CA residents please see CA CARB-Approved engine NTE Item# 60682).

Customers are responsible for checking local codes and regulations prior to purchase.

Displacement (cc) 205

HP 6.5

Application Tillers, log splitters, compressors and pressure washers

Torque (ft./lbs.) 8.75

Shaft Output Horizontal

Engine Type OHV

Start Type Recoil

Shaft Dimensions L x W (in.) 3/4 x 2 27/64

Mounting Base L x W (in.) 6.38 x 3.13

Bolt Circle (in.) 3 5/8

PTO Height (in.) 4.17

Shaft Keyway (in.) 3/16

Shaft End Tapped (in.) 5/16-24

Max. RPM 3,600

Charging System Amps N/A

Ignition System Magnetron® Electronic

Cylinders (qty.) 1

Fuel Tank Capacity (qt.) 3

Oil Capacity (qt.) 18-20 oz.

Air Cleaner Type Dual element includes automotive-type pleated paper air filter and foam pre-cleaner

Muffler Included Yes

Low Oil Alert No

Lubrication System Splash type

Shaft Rotation (From PTO Shaft Side) CCW

Bore x Stroke (in.) 2.69 x 2.20

Cylinder Bore Cast iron

Cooling System Air Cooled

Carburetor Float

Fuel Pump N/A

Governor System Mechanical

Flywheel Brake N/A

Idle Speed Control N/A

Auto Compression Release Yes

Dimensions L x W x H (in.) 12.4 x 16 x 17

EPA/CARB Approval (California Air Resource Board) No
